frame |
NS Bikes Synonym, alloy front triangle + carbon rear-end w/ 120mm travel 148x12mm dropouts |
sizes |
S,M,L |
rear shock |
X-Fusion O2 rlx+AC29X Trunnion 165x42.5 |
forks |
Rock Shox Recon Gold RL 120mm travel, 110x15mm Boost, 1.5T, 44mm offset |
headset |
FSA NO.42/47/ACB |
stem |
NS Bikes Synonym Trail 50mm, angle +5°, 31.8 |
handlebar |
NS Bikes Mini Rise Lite 31.8, 760mm, 10mm rise |
grips |
NS Bikes Hold Fast supersoft |
seatpost |
Kind Shock Rage i internal S: 120mm, M, L; 150mm |
saddle |
WTB Volt Medium Steel SL |
front brake |
Shimano MT410, 180mm |
rear brake |
Shimano MT410, 180mm |
rims |
WTB ST i27 TCS 2.0 29”, 28h, tubeless ready |
spokes |
Spokes w/14mm nipples |
front hub |
NS Bikes 110x15mm Boost (sealed bearings) |
rear hub |
NS Bikes 148x12mm Boost (sealed bearings) |
tires front / rear |
Maxxis Recon 2.4WT EXO/TR / Maxxis Ikon 2.35 EXO/TR |
crankset |
Shimano Deore FC-MT5101 170mm 32t |
bottom bracket |
Shimano BSA 73mm |
pedals |
/ |
chain |
Shimano Deore M6100, 12spd |
chain guide |
/ |
derailleur |
Shimano Deore M6100, 12spd |
shifters |
Shimano Deore M6100, 12spd |
cassette |
Sunrace CSMZ800, 11-51t, 12spd |
weight (kg) |
TBC |
|
* M size, tubeless setup |
