frame |
NS Bikes Synonym, carbon fibre w/ 120mm travel 148x12mm dropouts |
sizes |
S,M,L,XL |
rear shock |
Fox Factory Float DPS 2pos remote lockout, push-to-unlock, Evol LV Trunnion 165x42.5 |
forks |
Fox Factory 34 Step Cast Float FIT4, 120mm travel, 2pos remote lockout w/ Open Mode Adj, push-to-unlock, 15x110mm Boost, 1.5 tapered steerer tube, 44mm offset |
headset |
FSA NO.42/47/ACB |
stem |
NS Bikes Synonym Trail 31.8 50mm, angle +5° |
handlebar |
NS Bikes Licence Carbon Mini Rise Lite 31.8, 760mm, 15mm rise |
grips |
NS Bikes Hold Fast supersoft |
seatpost |
Fox Transfer Factory S: 120mm, M, L, XL: 150mm |
saddle |
WTB Volt Medium Cromoly |
front brake |
Sram Level TLM, 180mm |
rear brake |
Sram Level TLM, 180mm |
rims |
NSBikesxHunt 30 29", 32h, tubeless ready |
spokes |
Straight Pull Spokes |
front hub |
NSBikesxHunt straight pull 110x15mm Boost (sealed bearings) |
rear hub |
NSBikesxHunt straight pull 148x12mm Boost (sealed bearings) |
tires front / rear |
Maxxis Recon 2.4WT EXO/TR / Maxxis Ikon 2.35 EXO/TR |
crankset |
Sram X1 Carbon DUB 170mm 34t (XL size 175mm) |
bottom bracket |
Sram DUB Press Fit BB92 |
pedals |
/ |
chain |
Sram GX Eagle, 12 spd |
chain guide |
/ |
derailleur |
Sram X01 Eagle type 3 12spd |
shifters |
Sram GX Eagle, 12spd |
cassette |
Sram XG-1275, 10-50t 12 speed |
weight (kg) |
11.8 kg |
|
* M size, tubeless setup |
